Gauge-aware knitting chart maker

Fit an image to the shape of knitted stitches.

Use separate stitch and row gauge so the preview reflects knitted proportions instead of forcing every cell into a perfect square.

Private by design. Your image never leaves this browser.

Your pattern starts here

Choose an image to preview it with knitting-gauge proportions.

Start with the swatch

See the motif at knitted proportions.

Separate stitch and row gauge prevents a square-screen preview from hiding the stretch built into knitted fabric.

01 / Gauge

Stitches are not square

Separate stitch and row counts shape the chart so the finished motif is less likely to stretch vertically or horizontally.

02 / Colorwork

Plan a restrained yarn set

A sampled palette and color cap help turn photographic tone into manageable stranded or intarsia regions.

03 / Cleanup

Avoid lonely duplicate stitches

Confetti reduction removes isolated cells that would otherwise create awkward one-stitch color changes.

Gauge changes the picture

Design for knitted fabric, not a square computer grid.

Most knitting gauges have more rows than stitches per four inches, making each stitch cell physically wider than it is tall.

Enter washed, blocked gauge

Measure a generous swatch after washing and blocking it the way you will treat the final piece. Small gauge errors multiply across a large motif.

Choose stranded or intarsia structure

Stranded knitting favors short floats and repeating color areas; intarsia favors larger blocks. Review the cleaned chart for long jumps and single-stitch interruptions.

Keep shaping outside the image grid

The generated chart describes color placement on a rectangle. Garment shaping, stitch repeats, selvedges, and pattern grading still belong in the knitting pattern.

Good to know

Clear answers,
before you start.

Why are the knitting cells rectangular?

Knitted stitches are usually wider than they are tall. The preview uses stitch and row gauge to represent that physical proportion.

Which gauge numbers should I enter?

Use stitches and rows per four inches from a washed and blocked swatch in the actual yarn and colorwork method.

Can this create Fair Isle instructions?

It creates a color grid, but it does not automatically enforce float length, repeat symmetry, or traditional Fair Isle color rules.

Does it account for garment shaping?

No. Increases, decreases, necklines, and grading must be added in the surrounding knitting pattern.

How many yarn colors are practical?

That depends on method. Two to five is comfortable for many stranded motifs; intarsia can handle more separated blocks.

Is the image kept private?

Yes. It is processed locally and never uploaded.
